Lithium Coin Cells

Product Details

Batteries sold under the PREMIUM BATTERIES packaging brand feature the highest quality batteries from major manufacturers in the battery industry. The OEM brand is always facing outwards, and we use only top-quality brands, such as PANASONIC, MURATA (formerly SONY), MAXELL, RENATA, and TOSHIBA. The most significant advantages are long shelf life, excellent low temperature operation, high operating voltage, and excellent leakage resistance. Common applications are watches, vehicle key FOBs, memory backup, bike lights, portable electronic devices, and medical devices.

The current product line features a child-resistant packaging, utilizing a very secure and reliable trapped blister in a Natralock® tear-resistant paperboard, and meets the new packaging requirements for lithium coin cell batteries. Now available in a 1-piece, 2-piece, and 6-piece carded retail presentation.

  • Diverse Product Applications

    Audio equipment, calculators, cameras and light meters, data acquisition systems, electronic communication devices, electronic games, electronic wristwatches & clocks, hearing aids, industrial monitors/controls, medical equipment, memory backup, micro cassette recorders, remote keyless entry (Key FOB), security devices, transceivers and radios, small electronic instruments, and switchboards.

  • Characteristics and Advantages of Panasonic Lithium Coin Cells

    • High energy density.
    • High voltage.
    • Long shelf life.
    • Wide temperature range for operation (-40C to +60C) and storage (up to 10 year shelf life).
    • Underwriters Labs (UL) component recognition for selected types.
    • Leak resistant.
    • Suitable for pulse and continuous discharge.
    • Ideal standby power source.

PREMIUM LITHIUM COIN CELL RANGE

Panasonic | MuRata | Maxell | Renata | Toshiba

Model Rated Capacity
(mAh)
Nominal
Voltage
ANSI, NEDA Weight
(gram)
Diameter
(mm)
Height
(mm)
CR1/3N 160 3.0   11.6 10.8
CR927 30 3.0
CR1025 30 3.0 0.7 10.0 2.5
CR1216 25 3.0   0.7 12.5 1.6
CR1220 35 3.0 5012LC 1.0 12.5 2.0
BR1225 48 3.0   0.8 12.5 2.5
CR1612 40 3.0   0.8 16.0 1.2
CR1616 55 3.0   1.2 16.0 1.6
CR1620 75 3.0 5009LC 1.3 16.0 2.0
CR1632 140 3.0   1.8 16.0 3.2
CR2012 55 3.0   1.4 20.0 1.2
CR2016 90 3.0 5000LC 1.6 20.0 1.6
CR2020   3.0
CR2025 165 3.0 5003LC 2.3 20.0 2.5
CR2032 220 3.0 5004LC 2.9 20.0 3.2
CR2320 135 3.0   3.0 23.0 2.0
BR2325 165 3.0   3.0 23.0 2.5
CR2330 265 3.0   3.8 23.0 3.0
BR2335 300 3.0   3.4 23.0 3.5
CR2354 560 3.0   5.8 23.0 5.4
CR2412 100 3.0   2.0 24.5 1.2
CR2430 290 3.0 5011LC 4.6 24.5 3.0
CR2450 620 3.0 5029LC 6.3 24.5 5.0
CR2477 1000 3.0   10.5 24.5 7.7
CR3032 500 3.0   6.8 30.0 3.2

*Disclaimer: Whenever possible we strive to utilize the best quality brands for each model. Limited exceptions occur for very minor models which may not be available from any first rate manufacturer.

Check out our full range of silver oxide watch batteries, alkaline button and high voltage cells, lithium coin cells, and Premium Plus zinc air batteries.
